Products Details
Product Detail Specification
Features
- Designed for harsh environment.
- Aluminium extruded welded construction.
- Customised with any display size.
- Compact and efficient in cable management.
- Tailormade cooling systems.
- Optional Swivel arrangement for Display and Keyboard.
Compliances
- Mechanical :
- IEC 297, DIN41494
- IP :
- Upto IP 55
- EMI / EMC :
- MIL STD 461 F
- Shock and vibration :
- MIL STD 810 F and MIL STD 167
- Environmental specifications:
- JSS 55555
Construction
- Heavy duty aluminium special alloy extrusions and sheets.
- Welded Construction.
- Stainless steel hardware and internal parts.
- Chromated from inside and paintedfrom outside.
Size & Part No.
- DIS 2112 Series :
- Single Display
- DIS 2113 Series :
- Dual Display
- DIS 2114 Series :
- Tripple Display
Standard Size Available:
- Height :
- 1300MM / 1800MM overall
- Width :
- Usable 19
- Depth :
- Outer depth 600MM / 800MM / 1000MM
Product Detail Specification
Features
- Designed for harsh environment
- Aluminium extruded welded construction.
- Inside modular design compatible to 19inch standards.
- Compact and efficient in cable management.
- Tailormade cooling systems.
Compliances
- Mechanical :
- IEC 297, DIN41494
- IP :
- Upto IP 55
- EMI / EMC :
- MIL STD 461 F
- Shock and vibration :
- MIL STD 810 F and MIL STD 167
- Environmental specifications:
- JSS 55555
Construction
- Heavy duty aluminium special alloy extrusions and sheets.
- Welded Construction.
- Stainless steel hardware and internal parts.
- Chromated from inside and paintedfrom outside.
Size & Part No.
- DIS Series 2101 :
- Slim Version
- DIS Series 2111:
- Heavy Duty Version
Standard Size Available:
- Height :
- 10U / 12U / 16U/ 20U / 24U / 34U / 36U / 42U
- Width :
- 19 inch (Outer width 600MM or 700MM or 800MM)
- Depth :
- 400MM / 600MM / 800MM / 1000MM
Product Detail Specification
Features
- 19″ rack mountable or table top version.
- Welded or bolted construction of aluminium extrusions and sheet.
- Efficient-customised cooling systems.
- ESD clips provision for Guides or Aluminium Guides.
- Euro cards or vita based or CPCI based structures.
Compliances
- Mechanical :
- IEC 60297-3 /IEEE 1101.10 / 11
- IP :
- Upto IP 55
- EMI / EMC :
- MIL STD 461 F
- Shock and vibration :
- MIL STD 810 F and MIL STD 167
- Environmental specifications:
- JSS 55555
Construction
- Heavy duty aluminium special alloy extrusions and sheets.
- Welded Construction.
- Stainless steel hardware and internal parts.
- Chromated from inside and paintedfrom outside.
Size & Part No.
- DIS Series 33310 :
- VME-Rugged
- DIS Series 33410 :
- CPCI-Rugged
Standard Size Available:
- Height :
- 4U / 7U / 9U (vertical)
- Width :
- 19" compatible (85T)
- Depth :
- Flexible (with or without RTM)
Product Detail Specification
Features
- Designed for harsh environment
- Modular concept – with interchangeability
- Heavy duty aluminium special alloy extrusions and sheets.
- Welded plus bolted construction.
- Stainless steel hardware and internal parts.
Chromated from inside and painted from outside.
Compliances
- Mechanical :
- IEC 297, DIN41494
- IP :
- Upto IP 55
- EMI / EMC :
- MIL STD 461 F
- Shock and vibration :
- MIL STD 810 F and MIL STD 167
- Environmental specifications:
- JSS 55555
Construction
- Heavy duty aluminium special alloy extrusions and sheets.
- Welded Construction.
- Stainless steel hardware and internal parts.
- Chromated from inside and paintedfrom outside.
Size & Part No.
- DIS Series 2541,2602
Standard Size Available:
- Height :
- 3U / 4U / 6U
- Width :
- 21T / 42T / 63T / 84T
- Depth :
- Can be Customized
Product Detail Specification
Features
- Plain as well as Shielded designs.
- Customize front panels with I/O cutouts and silk screening.
- Multiple pulling options for smooth operations.
- RoHS compliant rich conductive finish.
- Multiple width options.
Compliances
- Mechanical :
- IEC 297, DIN41494
- IP :
- Upto IP 55
- EMI / EMC :
- MIL STD 461 F
- Shock and vibration :
- MIL STD 810 F and MIL STD 167
- Environmental specifications:
- JSS 55555
Construction
- Heavy duty aluminium special alloy extrusions and sheets.
- Welded Construction.
- Stainless steel hardware and internal parts.
- Chromated from inside and paintedfrom outside.
Size & Part No.
- DIS Series 2541,2602
Standard Size Available:
- Height :
- 3U / 4U / 6U
- Width :
- 21T / 42T / 63T / 84T
- Depth :
- Can be Customized
Product Detail Specification
Features
- Designed for harsh environment
- Shock and vibration resistant.
- Heavy duty aluminium special alloy extrusions and sheets.
- Welded plus bolted construction.
- Stainless steel hardware and internal parts.
Chromated from inside and painted from outside.
Compliances
- Mechanical :
- IEC 297, DIN41494
- IP :
- Upto IP 55
- EMI / EMC :
- MIL STD 461 F
- Shock and vibration :
- MIL STD 810 F and MIL STD 167
- Environmental specifications:
- JSS 55555
Features
- Heavy duty aluminium special alloy extrusions and sheets.
- Welded Construction.
- Stainless steel hardware and internal parts.
- Chromated from inside and paintedfrom outside.
Compliances
- DIS Series 2541
Standard Size Available:
- Height :
- 2U to 10U
- Width :
- 19 inch
- Depth :
- 400MM / 600MM / 800MM / 1000MM
Related Products
DIS - 2574
DIS - 2574
DIS - 2574
Product Detail Specification
Features
- Designed for harsh environment
- Shock and vibration resistant.
- Heavy duty aluminium special alloy extrusions and sheets.
- Welded plus bolted construction.
- Stainless steel hardware and internal parts.
Chromated from inside and painted from outside.
Compliances
- Mechanical :
- IEC 297, DIN41494
- IP :
- Upto IP 55
- EMI / EMC :
- MIL STD 461 F
- Shock and vibration :
- MIL STD 810 F and MIL STD 167
- Environmental specifications:
- JSS 55555
Features
- Heavy duty aluminium special alloy extrusions and sheets.
- Welded Construction.
- Stainless steel hardware and internal parts.
- Chromated from inside and paintedfrom outside.
Compliances
- DIS Series 2541
Standard Size Available:
- Height :
- 2U to 10U
- Width :
- 19 inch
- Depth :
- 400MM / 600MM / 800MM / 1000MM
Related Products
DIS - 2574
DIS - 2574
DIS - 2574
Product Detail Specification
Features
Heavy duty aluminium extrusions and CRCA covers Compact and efficient in cable management Multiple door options – including perforated Secured locking systems Can be supplied in Semi Knocked Down kit IP 55 & EMC racks are offerred in Assembled condition only.
Compliances
- Mechanical :
- IEC 297, DIN41494
- IP :
- Upto IP 55 design
- EMI / EMC :
- MIL STD 461 F
Construction
- Heavy duty aluminium special alloy extrusions and CRCA covers.
- Bolted construction.
- MS plated or stainless steel hardware.
- Powder coated finish.
Size & Part No.
- DIS Series 1011
Standard Size Available:
- Height :
- 12U / 16U / 20U / 24U /32U /36U / 42U
- Width :
- 19 inch (Outer width 800 MM)
- Depth :
- 800MM / 1000MM
Product Detail Specification
Features
- 19″ rack mountable or table top version.
- GFN guides with ESD clips as well as Aluminium Guides.
- Provision for rear I/O card.
- Customised cooling systems.
- EMC upgradable design.
- Optional Integration with backplanes and wire harness.
Compliances
- Mechanical :
- IEC 297, DIN41494, IEEE 1101.10 / 11
- IP :
- Upto IP 20
- EMI / EMC :
- Optional EMC compliance as per IEC 60297-3
- Shock and vibration :
- No
Construction
- Aluminium special alloy extrusions and sheets.
- Bolted construction.
- Stainless steel hardware.
- Rear I/O provision (optional).
Features
- DIS Series 2331
- VME
Standard Size Available:
- Height :
- 2U/3U (horizontal) and 4U/7U/9U (vertical)
- Width :
- 19" compatible (85T)
- Depth :
- Flexible (with or without RTM)
Related Products
DIS - 1301 D
DIS - 1301 D
DIS - 1301 D
Product Detail Specification
Features
- 19″ rack mountable or table top version.
- Compatible to euro cards of different sizes.
- Provision for rear I/O card.
- Customised cooling systems.
- Glass filled nylon guides – press fit type for PCBs.
- Guides can be removed without removing top/bottom.
Compliances
- Mechanical :
- IEC 297, DIN41494, IEEE 1101.10 / 11
- IP :
- Upto IP 40
- EMI / EMC :
- Optional EMC compliance
- Shock and vibration :
- No
Construction
- Aluminium special alloy extrusions and sheets.
- Screw type construction.
- Glass filled nylon guides – press fit type for 1.6 or 2.4 mm thick PCB.
- Stainless steel or ms plated hardware.
Features
- DIS Series 1303
Standard Size Available:
- Height :
- 3U to 12U
- Width :
- 19" compatible (21T / 42T / 63T/ 84 T)
- Depth :
- Can be customised
Related Products
DIS - 1301 D
DIS - 1301 D
DIS - 1301 D
Product Detail Specification
Features
- 19″ rackmountable full aluminium racks.
- Ventilation options from all sides for better cooling.
- Customised front and rear panel, also with hinges.
- Aluminium or CRCA base plate for components.
- Powder coated / annodised / chromated surfaces.
- Heavy Duty customised racks for extra load.
Compliances
- Mechanical :
- IEC 297, DIN41494, IEEE 1101.10 / 11
- IP :
- Upto IP 40
- EMI / EMC :
- Optional EMC compliance
- Shock and vibration :
- No
Construction
- Aluminium special alloy extrusions and sheets.
- Bolted construction.
- Stainless steel hardware.
- Rear I/O provision (optional).
Features
- DIS 1511 - 1U Series
Standard Size Available:
- Height :
- 3U to 12U
- Width :
- 21T / 42T / 63T /84T
- Depth :
- Can be customised
Related Products
DIS- 1513 B
DIS- 1513 B
DIS- 1513 B
Product Detail Specification
Features
- Table top version.
- Full aluminium construction.
- Round corners with minimum visible screws.
- Front and rear screwless with optimised usable area.
- Chassis mount as well as card rack design inside.
- Powder coated / annodised / chromated surfaces.
Compliances
- Mechanical :
- IEC 297, DIN41494, IEEE 1101.10 / 11
- IP :
- Upto IP 40
- EMI / EMC :
- Optional EMC compliance
- Shock and vibration :
- No
Construction
- Aluminium special alloy extrusions and sheets.
- Screw type construction.
- Aluminium or CRCA base plate for components.
- Card racks with GFN guides for PCBS-EURO/VME/CPCI.
- Legs – plastic.
Features
- DIS 1511 - 1U Series
- DIS 1512 - 2U Series
- DIS 1513 - 3U Series
Standard Size Available:
- Height :
- 1U
- Width :
- 19" compatible (21T / 42T / 63T/ 84 T)
- Depth :
- Can be customised
